Vertical Axial Flow Pump

In order to make available high quality product range, we make use of the finest grade raw material that is sourced from the trusted places after complete assurance of the quality. Backed by efficient logistics team, we make deliveries of the goods in the set time span.

Applications :

• Flood Control,
• Water Treatment,
• Shipping,
• Ground Water Development and Irrigation,
• Cooling Water (power),
• Dewatering and Water Supply (mining),
• Agriculture

Industries :

• Mining
• Water Resources
• Power Generation
• General Industries

Three- or Four-Vane Axial Flow Propeller is hydraulically balanced via pressure equalizing balance holes and a top propeller hub wear ring to reduced axial down thrust.

Outer Flanged Columns are bolted together with through bolts for ease in assembly. Alignment is maintained via centering fits on all parts.

Flared Suction Bell provides a smooth waterway entrance to the impeller and has integral splitters to reduce inlet swirl and entrance losses.

Stator Case With Integral Diffuser Vanes may be either a single-piece casting or a fabrication.

Discharge Elbow may be located above or below ground and at any outlet orientation.
Seal Chamber accepts packing or mechanical seal to suit service requirements.

Characteristics

• Multi-stage vertical centrifugal pump, diffuser type bowl.
• Axial flow impeller, high efficiency.
• Can handle solids up to 14'' diameter (365 mm).
• Counter clockwise rotation viewed from shaft coupling.
