Creative Engineers

Monoblock Pump

Monoblock Pump
Business Type Manufacturer, Exporter, Supplier, Retailer
Application Water Supply
Weight 10-15kg
Voltage 220V
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Theory
Self-priming
Automatic Grade
Semi Automatic
Power
2Kw
Driven Type
Electric
Pressure
1-5Bar
Warranty
1year

located in ahmedabad(india), we are actively involved in bringing forth a high quality array of products in the market. We ensure the products we provide buyers with are as per international quality management systems.



features :

  • can withstand wide voltage fluctuation – from 300-440 volts.
  • suction lift up to 7.5 meters.
  • top flat efficiency curve : minimum variation in efficiency in entire operating range
  • efficiency at par with internationally available pumps – higher up to 10 points than minimum required by indian standards specification
  • models are with ip – 44 protection. Models with ip – 55 protection are also available on request
  • class of insulation ‘b’ ( ‘f’ class for 9.3 kw and 11.0 kw ratings).
  • designed to prevent overloading and motor burning
  • dynamically balanced rotating parts ensure minimum vibrations
  • replaceable wearing parts and hence longer life
  • designed for automatic air release during priming
  • continuous rated motor
  • inside and outside of pump covered  by  anticorrosive paint


applications :

  • industries for clear water handling
  • water supply for domestic use in apartments, buildings and hotels.
  • mmp series three phase pumps : single stage, high speed horizontal, centrifugal , monobloc with volute type delivery casing


range :

  • head : 6-52 meters
  • capacity : 19.0-2.0 liters per second
  • power rating : 0.37 kw to 5.5 kw (0.5 hp to 7.5 hp )


material of construction standard supply :

  • impeller : cast iron
  • delivery casing : cast iron
  • motor body : cast iron
  • shaft : en -8
  • shaft sleeve : ss-410


optional supply :

  • impeller : bronze / stainless steel
  • shaft : stainless steel
  • shaft sleeve : chrome steel
Read More...
