Screw Pump

Screw Pump

Product Details

Flow Rate Up to 100 M3 / Hr
Differential Pressure 24 Bar
Viscosity Up to 1,00,000 Cst
Temperature Up to 150°C
Suction Lift 8 mlc Max
Download View

Applications : The main components which characterize the pump are a metallic single helical rotary part ROTOR and fixed double helical resilient polymer part STATOR in which the rotor turns and thereby a complex progressive sealing line (cspl) is maintanined. Whilst the rotor rotates inside the stator, the cavities formed between them progresses from suction to discharge end, gently carrying the media.



Drive Arrangements :

  • DIRECT drive lectric motor, geared motor, gear box, Mechanical Speed Variator, Eddy Current DC Drive, Hydraulic, Pneumatic, Petrol & Diesesl Engines.
  • For accurate and variable flow rates, AC Variable frequenc Drives can be used.



Material Options :

  • Housing Parts : AISI304, AISI316, AISI316L
  • Rotor & Shaft : AISI304, AISI316, AISI316L
  • Stator : NBR, HNBR, EPDM, CSM, Q



White, food grade, abrasion resistant & high temperature resistant variants.
